Economical Crimping Machine
SAMWAY S102 CRIMPIMG MACHINE
Model: S102
* Full Automatic Precision Control * Affordable 6 inch Industrial Hose * Energy Saving and Safety Operation * CE Approved
Options & Accessories
| Options | |
|---|---|
| backstop device | 110V/220V 1 Phase |
| 230V/440V/480V 3 phase |
Technical Specifications
Max Hose4"
Max Hydraulic Hose2"6sp
Maximum Industrial Hose140mm ID
Crimping Range(mm)10-140
Die Type51
Master Die Length(mm)80
Max Opening(mm)1)+24
Motor Power(KW/HP)1)4.0/5.0(400V 3 Phase)
Crimping Force(KN)2800
Crimpings per Hour550
Foot Pedalincluded
Noise Level (dBA)65
Protection ClassIP56
DIMENSIONS
| Machine(mm) | 750x450x1450 |
|---|---|
| Machine(inch) | 29.5x17.7x57.1 |
| Packaged(mm) | 850x550x1600 |
| Packaged(inch) | 33.5x21.7x63.0 |
WEIGHT
| Machine(kg/lbs) | 400/882 |
|---|---|
| Packaged(kg/lbs) | 420/926 |
DIE SET 51-SERIES
| DieSetNo | D(mm) | L(mm) | Crimp.range(mm) |
|---|---|---|---|
| *18506/10 | 10 | 60 | 10.1-12.0 |
| 18506/12 | 12 | 60 | 12.0-14.0 |
| 18506/14 | 14 | 60 | 14.0-16.0 |
| 18506/16 | 16 | 60 | 16.0-19.0 |
| 18506/19 | 19 | 60 | 19.0-22.0 |
| 18506/22 | 22 | 75 | 22.0-26.0 |
| 18506/26 | 26 | 75 | 26.0-30.0 |
| 18506/30 | 30 | 75 | 30.0-34.0 |
| 18506/34 | 34 | 80 | 34.0-39.0 |
| 18506/39 | 39 | 80 | 39.0-45.0 |
| 18506/45 | 45 | 90 | 45.0-51.0 |
| 18506/51 | 51 | 90 | 51.0-57.0 |
| 18506/57 | 57 | 100 | 57.0-63.0 |
| 18506/63 | 63 | 100 | 63.0-69.0 |
| 18506/69 | 69 | 100 | 69.0-74.0 |
| 18506/74 | 74 | 110 | 74.0-78.0 |
| 18506/78 | 78 | 110 | 78.0-87.0 |
